40A100V SBT40L100FCT Low VF Schottky Diodes For Frequency Multipliers
Part
Number |
Package |
Die |
Io
(A) |
VBR
@IR |
VF(25℃)
@IF |
IR(25℃)
@VBR |
VF(125℃)
@IF |
IR
(125℃ |
IFSM
(A) |
Tj
(℃) |
Min
(V) |
IF
(A) |
Typ
(V) |
Max
(V) |
Typ
(uA) |
Max
(uA) |
IF
(A) |
Typ
(V) |
Typ
(mA) |
| SBT40L100FCT |
TO-220F |
2 |
40 |
100 |
15 |
0.64 |
0.73 |
11 |
50 |
- |
- |
- |
220 |
150 |
Product Description:
The SBT Low VF Schottky diode is characterized by its fast switching speed, which makes it well-suited for use in high-frequency circuits. This diode also has a very low forward voltage, which helps to minimize power loss and improve overall efficiency. Its low reverse recovery time further enhances its performance, making it an excellent choice for use in power supplies, motor control circuits, and other high-power applications.
In addition to its impressive performance characteristics, the SBT40L100FCT Low VF Schottky diode is also designed to operate over a wide temperature range, from -55°C to +150°C. This makes it suitable for use in harsh environments where other diodes might fail.
The SBT40L100FCT Low VF Schottky diode is available in two package options – TO-220F – to provide flexibility in design and application. Both packages are RoHS compliant, ensuring that the diode meets the latest environmental standards.
Overall, the SBT40L100FCT Low VF Schottky diode is a reliable and high-performing diode that is perfect for a wide range of applications. Its very low forward voltage, high efficiency, and low reverse recovery time make it an ideal choice for power supplies, motor control circuits, and other high-power applications where performance and reliability are critical.
Features:
- Product Name: Low VF Schottky
- Characteristics:
- Fast Switching Speed
- High Efficiency
- Low Reverse Recovery Time
- Model Number: SBT40L100FCT
- Package:
- Rohs Compliant: Rohs
- Operating Temperature Range: -55°C To +150°C
This product is ideal for use in Motor Drives, switching power supply, and adapter applications.
Technical Parameters:
| Characteristics |
Fast Switching Speed, High Efficiency, Low Reverse Recovery Time |
| Model Number |
SBT40L100FCT |
| Application |
Power Supply Units, Motor Drives, RF Amplifiers, Wireless Communications |
| Package |
TO-220F |
| Operating Temperature Range |
-55°C To +150°C |
| Rohs Compliant |
Yes |
The Low VF Schottky product is known for its robustness, fast switching capability, and low reverse recovery time. Its model number is SBT and it is commonly used in power supply units, motor drives, RF amplifiers, and wireless communications. It comes in TO-220AB and TO-220F packages and can operate in temperatures ranging from -55°C to +150°C. This product is also Rohs compliant.
Applications:
The Low VF Schottky product from Lingxun has two package options: TO-220F. These products are known for their fast switching speed, high efficiency, and low reverse recovery time. They can operate in a wide temperature range of -55°C to +150°C.
These products have various application occasions and scenarios. For example, they can be used in power supply units, motor drives, RF amplifiers, wireless communications, and more. Due to their low reverse recovery time and high efficiency, they are ideal for use in switching power supplies. They can also be used in industrial control systems because of their reliable performance in extreme temperature conditions.
Lingxun's Low VF Schottky product is RoHS compliant, making it environmentally friendly. Customers can confirm the quantity, price, and package details with the company.
Customization:
Brand Name: Lingxun
Place of Origin: China
Certification: ISO9001, ISO14001, ROHS, REACH
Minimum Order Quantity: Confirm quantity based on part number
Price: Confirm price based on part number
Packaging Details: Confirm package based on part number
Delivery Time: Confirm
Payment Terms: T/T payment
Supply Ability: 600KK/year
Application: Power Supply Units, Motor Drives, RF Amplifiers, Wireless Communications
Model Number: SBT40L100FCT
Operating Temperature Range: -55°C To +150°C
Rohs Compliant: Rohs
Package: TO-220F
Product Attributes: Fast Switching Speed, industrial control system, Power Supply Units.
